GRACES Commercial Escalator

Name: GRACES
Brand: IFE ELEVATORS CO., LTD.

IFE Elevator focuses on the Research and Developmenttherefore,our R & D department has over 200 professional engineer. Until now,we have gotten over 200national patent.

Features Of GRACES Commercial Escalator

No need to install a machine room on the top of the building and consider buffer pits on the ground floor, taking up less space than elevators
Continuous and rapid evacuation of a large number of people

Specification Of GRACES Commercial Escalator

Specification			GRACES-ID

Lifting height range/m			1.5≤H≤13.0
Use segment length/m			--
Tilt angle/°			30/35
Nominal width/mm			600/800/1000
Nominal speed/m/s			0.5
Applicable environment			Indoors
The type of work			Normal type
Handrail structure			Vertical armrests
Drag method			Y-△/VVVF
Startup mode			Standard single speed Standard self-starting Frequency conversion low speed Frequency conversion self-starting



Number of horizontal steps as standard	H≤6m		2
	H>6m		3
Pedal depth/mm as standard			--
Additional brakes		H≤6m	No
		H>6m	Yes
Truss deflection			≤1/750
Safety factor for moving parts			≥5

Specification			GRACES-Ⅲ

Lifting height range/m			1.5≤H≤13.0
Use segment length/m			--
Tilt angle/°			30/35
Nominal width/mm			600/800/1000
Nominal speed/m/s			0.5
Applicable environment			Outside
The type of work			Normal type
Handrail structure			Vertical armrests
Drag method			Y-△/VVVF
Startup mode			Standard single speed Standard self-starting Frequency conversion low speed Frequency conversion self-starting



Number of horizontal steps as standard	H≤6m		2
	H>6m		3
Pedal depth/mm as standard			--
Additional brakes		H≤6m	No
		H>6m	Yes
Truss deflection			≤1/750
Safety factor for moving parts			≥5

Specification			GRACES-LD

Lifting height range/m			1.5≤H≤18
Use segment length/m			--
Tilt angle/°			27.3/30
Nominal width/mm			600/800/1000
Nominal speed/m/s			0.5/0.65
Applicable environment			Indoor/Outdoor
The type of work			Public transport type
Handrail structure			Vertical armrests
			Stainless steel diagonal armrest
Drag method			VVVF
Startup mode			Frequency conversion low speed Frequency conversion self-starting



Number of horizontal steps as standard	H≤6m		3
	H>6m		3
Pedal depth/mm as standard			--
Additional brakes		H≤6m	Yes
		H>6m	Yes
Truss deflection			≤1/1000
Safety factor for moving parts			≥5
